265 (14 Ton)

6 Wheel Model

14 ton tandem wagon gear
Quick hitch tongue
Standard reach length 11'
Wheel Base adjustable 8' 8" - 11' 2"
Hubs - 8 Bolt 6,500 LBS. each
Safety chain (1/2" GR. 70)

Capacity	28,000 lbs.
Spindles	2-1/4" Dia. C1045 Cold Rolled
Hubs (max. speed rating 20 mph)	8 Bolt 6,500 lbs. each
Bearings - Bore Size (Inner/Outer)	Taper Roller 1.80/1.38
Front Axle	7 x 3 x .250 Wall
Rear Axle	7 x 3 x .313 Wall
Tongue Bracket Mounting	1-1/2" Bolt Bearing Mtd.
Tongue Bolt	1-1/8" Dia.
Tongue Latch	Retractable Automatic Relock - Standard on all Models
Reach Poles	3" O.D. x .188 Wall - Round Tube
Bolster Stakes	42.5" Fixed
Steering	Automotive Type
Tie Rod Ends	Greasable Automotive Style Ball Joints
Wheel Base	Adjustable
Height from Ground to Top of Bunk	26" (12.5 x 16 Tires) 30" (11 x 22.5 Tires)
Approx. Weight	1,155 lbs. (less rims and tires)

Optional Reach Lengths: 9', 11', 12', 14', 16', 18', 20', 22'

Add or subtract price per foot for over or under 11' (includes both reach poles)

Narrow track (Custom Build) down to 60"

Wide Track (Custom Build) up to 90"

2 wheel free backing surge brakes c/w double spring balancer (includes brake tongue)

4 wheel surge brakes

Single spring balancer

Double spring balancer

Rocking bolster

Rocking bolster for ammonia tank

4" bolt on riser kit (other heights available)

Tire Size	Tire Type	Rim Size	Track Width	Capacity (LBS/Tire)
12.5L x 15	12 Ply	15 x 10 x 8	82"	3,640
12.5L x 16	14 Ply	16 x 10 x 8	82"	4,180
12.5L x 15	F Range / Hwy Ser.	15 x 10 x 8 HD	82"	4,680
14L x 16.1	8 Ply	16.1 x W11C x 8	82"	3,860
14L x 16.1	12 Ply	16.1 x W11C x 8	82"	4,680

Capacities listed are max tire capacity. See wagon specifications for maximum wagon capacity.
