Tire Options
- New Implement - Farm
- New Implement - Highway
- New/Used Truck Tires
- Recap Truck Tires
| Tire |
Approx. Height |
Ply |
Capacity (Lbs/tire) |
Description |
| 26 x 12 |
26" |
12 Ply |
2,750 |
Tubeless Tires on 12 x 10.5 x 6 rims |
| 11L x 15 |
31" |
8 Ply |
2,540 |
Farm Utility Tubeless |
| 12.5L x 15 |
32.25" |
12 Ply |
3,640 |
Farm Utility Tubeless |
| 12.5L x 16 |
33" |
14 Ply |
4,180 |
Farm Utility Tubeless |
| 14L x 16.1 |
36.75" |
8 Ply |
3,860 |
Farm Utility Tubeless |
| 14L x 16.1 |
36" |
12 Ply |
4,680 |
Farm Utility Tubeless |
| 16.5 x 16.1 |
40.5" |
10 Ply |
5,200 |
Farm Utility Tubeless |
| 19L x 16.1 |
42.25" |
12 Ply |
6,000 |
Farm Utility Tubeless |
| 21.5 x 16.1 |
44" |
14 Ply |
7,850 |
Farm Utility Tubeless |
| Tire |
Approx. Height |
Load Range |
Capacity (Lbs/tire) |
Description |
| 20.5 x 8-10 |
20.5" |
F |
1,650 |
Tires on 10 x 6 x 6 rims |
| 225/75 R15 |
28" |
D |
2,540 |
Highway Trailer Tubeless Tires on 15 x 6 x 6 rims |
| 235/85 R16 |
31.5" |
F |
3,960 |
Highway Trailer Tubeless Tires on 16 x 8 x 6 rims |
| 235/75 R17.5 |
31.4" |
16 Ply |
6,005 |
Highway Service Tubeless Tires on 17.5 x 6.75 x 8 rims |
| 400/55 x 22.5 |
40.2" |
16 Ply |
7,820 |
Highway Flotation Tubeless Tires on 22.5 x 13 |
| 560/45 x 22.5 |
42.1" |
16 Ply |
9,640 |
Highway Flotation Tubeless Tires on 22.5 x 16 |
| 11L x 15 |
30.5" |
D |
3,120 |
Highway Service Tubeless Tires Must be used with HD rims |
| 11L x 15 |
31.25" |
F |
3,960 |
Highway Service Tubeless Tires Must be used with HD rims |
| 11L x 15 |
31.5" |
F |
3,690 |
Highway Service Tubeless Tires for Header Wagon |
| 12.5L x 15 |
33.5" |
F |
4,680 |
Highway Service Tubeless Tires Must be used with HD rims |
| Tire |
Approx. Height |
Tubeless |
Capacity (Lbs/tire)* |
Rim Size Required |
| 245 R16 |
30" |
Tubeless |
3,500 |
16 x 8 |
| 11 x 22.5 |
40.5" |
Tubeless |
8,000 |
22.5 x 8.25 HD |
| 12 or 315 x 22.5 |
39" |
Tubeless |
8,000 |
22.5 x 8.25 HD |
| 385 x 22.5 (15 x 22.5) |
41.75" |
Tubeless |
10,000 |
22.5 x 11.75 |
| 425 x 22.5 (16 x 22.5) |
44" |
Tubeless |
12,000 |
22.5 x 13 / 22.5 x 11.75 |
| Tire |
Approx. Height |
Tubeless |
Capacity (Lbs/tire)* |
Rim Size Required |
| 11 x 22.5 |
41" |
Tubeless |
8,000 |
22.5 x 8.25 HD |
| 12 or 315 x 22.5 |
42.75" / 42.5" |
Tubeless |
8,000 |
22.5 x 8.25 HD |
| 305 x 22.5 |
39" |
Tubeless |
8,000 |
22.5 x 8.25 HD |
| 425 x 22.5 (16 x 22.5) |
44.5" |
Tubeless |
12,000 |
22.5 x 13 / 22.5 x 11.75 |
Capacities listed are max tire capacity. See wagon specifications for maximum wagon capacity.
