| Maximum Rated Gross Capacity | 24,000 lbs. |
| Wheelbase | 48' (Standard) |
| Tongue Length (Adjustable) | 11'-10" to 14'-9" |
| Top Rail Length | 64' |
| Maximum Head Size | 62' |
| Safety Chains | Standard |
| Approx. Weight | 7,845 lbs. (less rims and tires) |
| CHCFXFK | Fender kit - keep your header protected from road debris |
| CHCFSTC | Spare tire carrier kit |
| CHCFXMD261 | Hardware kit upgrade with supports for Macdon FD261 Header |
| HBAFK | Honey Bee AirFLEX® Pad Adapter Kit |
| WAS8 | Setup charge |
| Tire Size | Description | GVWR | Rim Size |
| 235/75 R17.5 | 16 Ply | 24,000 lbs. | 17.5 x 6.75 x 8 |
Capacities listed are max tire capacity. See wagon specifications for maximum wagon capacity.
