| Maximum Rated Gross Capacity | 10,000 lbs. |
| Wheelbase | 18' |
| Tongue Length (Adjustable) | 11' 3" to 12' 9" |
| Top Rail Length | 31' |
| Maximum Head Size | 30' |
| Safety Chain | Standard |
| Shoes & Pads | 2 Shoes + 2 small Pads Included |
| Approx. Weight | 1,820 lbs. (less rims and tires) |
Maximum Rated Gross Capacity changes depending on tire option
| CHCLPO | Upgrade option to Universal Pad (upgrade includes both pads)(in lieu of standard pad at time of manufacture) |
| LK18 | Road Signal Light Kit (18' wheelbase) |
| CHCRB18HD | Heavy duty bottom rail option - is designed for headers that require extra support along the mid section. (in lieu of standard rail at time of manufacture) |
| HBAFK | Honey Bee AirFLEX® Pad Adapter Kit |
| SB | Single Spring Tongue Balancer |
| SBD | Double Spring Tongue Balancer |
| CHCTRMX2 | Extends top rail horizontal adjustment up to 10" (incl. 2 extensions and 4 pins) |
| Tire Size | Description | GVWR | Rim Size |
| 20.5 x 8 - 10 | F Range | 6,600 lbs. | 10 x 6 x 6 |
| 26 x 12 | 12 ply | 10,000 lbs. | 12 x 10.5 x 6 |
| 225/75 R15 | D Range highway trailer tire | 10,000 lbs. | 15 x 6 x 6 |
| 235/85 R16 | F Range highway trailer tire | 10,000 lbs. | 16 x 8 x 6 |
| 11L x 15 | F Range highway service tire | 10,000 lbs. | 15 x 8 x 6 HD |
Capacities listed are max tire capacity. See wagon specifications for maximum wagon capacity.
